Max PTZ Control

Cam Menu

Worship

Sermon

Disable

Set

DYNAMIC MOVEMENT

NAN

Slow

Custom

Fast

ZOOM OUT

ZOOM IN

PAN LEFT

PAN RIGHT

CONNECTING TO ATEM

ATEM SWITCHER CONTROLS

LOWER 3RDS

PiP SLIDES

SLIDES

LEFT

CENTER

RIGHT

Cut

Auto

TRANSITION

EXPOSURE

AUTO

NAN

RESET

Camera Offline

CONNECTING TO CAMERAS

Drums

Piano

Aux

Guitar

Bass

Left

Mid Left

Center

Mid Right

Right

Stage Wide

Stage Medium

Stage Closeup

Creative 1

Creative 2

Creative 3

Help

Exit

0m 45s

Auto Mix

AF Lock

LIVE

REC

CONNECTING TO STREAMING DEVICES

PLANNING CENTER

EMERGENCY BRAKE

JOYSTICK MODE

Reversed

Normal

Keyboard

DEVICE CONNECTIONS

Bypass

DEVICE CONNECTIONS

Reset

WINDOW SESSION

Save

WINDOW SESSION

Clear

PLANNING CENTER

Refresh

PTZ APP

Reload

Exit Help

CAM MENU

Opens On Screen Display (OSD) menu in PTZ Optics camera. In this menu you can adjust camera settings such as Iris, Shutter Speed, Color Temp, etc.

LAYOUT MODE

Changes "Preset Button" layout between Worship and Sermon. Selecting correct layout will declutter preset buttons during sermon and vise-versa.

DISABLE

Disables not needed preset buttons. When button is activated, touching preset button will disable it. Touching again will enable it.

SET

When button is activated, all preset buttons are in SET mode. When button is not activated, preset buttons are in RECALL mode.

AUTO MIX

When enabled, cameras will automatically transition from left to right. Cycle interval can be adjusted with Auto Mix Time.

AF LOCK

Auto-Focus Lock. When enabled, camera will no longer auto-focus. It is recommended to lock focus to prevent focus ghosting.

SAVE / CLEAR SESSION

Session is your custom window layout, such as presets, disabled buttons, etc. This data is needed in case app crashes and needs to be reloaded. Session is automatically saved every 10 min, but if needed, press button to SAVE session now. CLEARING session will reload app with default layout.

REFRESH PLANNING CENTER

Refresh Planning Center data. Data is automatically refreshed every 5 min, but if needed, press button to refresh data now.

DEVICE CONNECTION RESET/BYPASS

Connection reset or bypass. If connection between cameras and ATEM has not been established, press "RESET" to continue attempting to connect. "BYPASS" will end connection attemps remove connection messages.

JOYSTICK XYZ

Push Stick Forward (NORMAL)

CAMERA TILT UP

Push Stick Backward (NORMAL)

CAMERA TILT DOWN

Push Stick Forward (REVERSED)

CAMERA TILT DOWN

Push Stick Backward (REVERSED)

CAMERA TILT UP

Push Stick Left

CAMERA PAN LEFT

Push Stick Right

CAMERA PAN RIGHT

Rotate Stick Head Left

CAMERA ZOOM OUT

Rotate Stick Head Right

CAMERA ZOOM IN

Push Left Head Button

CAMERA FOCUS OUT

Push Right Head Button

CAMERA FOCUS IN

CAMERA SETTINGS

EXPOSURE

Iris: F1.8
Shutter: 1/60
Gain: 2
DRC: 3

COLOR

ColorTemp: 4000K
Saturation: 100%
Hue: 7


Luminance: 4
Contrast: 10
Sharpness: 2
Gamma: Default
Style: Default

NOISE REDUCTION

NR2D-Level: 2
NR3D-Level: 3

JOYSTICK BUTTONS

Button 1

SELECT PREV CAM

Button 2

SELECT NEXT CAM

Button 3

SLOW FOCUS OUT

Button 4

SLOW FOCUS IN

Button 5

SLOW ZOOM OUT

Button 6

SLOW ZOOM IN

Button 7

SLOW PAN LEFT

Button 8

SLOW PAN RIGHT

Button 9

SLOW TILT DOWN

Button 10

SLOW TILT UP

Launch App

WARNING: LIVE-STREAM AND/OR RECORDING IS ACTIVE
PRESS AUTO END TO AUTO END LIVE-STREAM AND RECORDING
